Name: DS-7204HGHI-F1 HIKVISION 4CH DVR 4 CHannel Turbo HD 1080P
Brand: HIKVISION
SKU: 837437748699-QT1
Price: 71.99 USD

DS-7204HGHI-F1 HIKVISION 4CH DVR 4 CHannel Turbo HD 1080P

HIKVISION
Share
- WhatsApp
- Deel
- X
- Pin it
- Messenger
- Email

DS-7204HGHI-F1 HIKVISION 4CH DVR 4 CHannel Turbo HD 1080P

HIKVISION
Share
- WhatsApp
- Deel
- X
- Pin it
- Messenger
- Email

Product form

Out of stock, 10 Business Days Mid weeks
Monday to Friday we offer same day handling if the product is on stock and exceptions on holidays.

Weekends
We offer no deliveries in the weekends.

International
Depending on where you’re located, we offer next day delivery. Check status on this link

$79.19 $71.99

Shipped today? Order within: Dec 25, 2025 14:00:00 -0500

Guaranteed secure & safe checkout.

Free shipping on all orders

No hassle returns, 30 days return

Data sheet PDF

Product Description

4ch 1080p Lite 1U H.264 DVR

4chs and 1 HDD 1U DVR
H.264+ / H.264 video compression
Encoding ability up to 1080p lite @ 25/30 fps
5 signals input adaptively ("Hybrid")
Up to 5 network cameras can be connected

Specification

Recording
Video CompressionH.264+/H.264
Encoding ResolutionWhen 1080p Lite mode not enabled: 720p/WD1/4CIF/VGA/CIF,When 1080p Lite mode enabled: 1080p lite/720p/WD1/4CIF/VGA/CIF
Frame RateMain stream: ,When 1080p Lite mode not enabled:,For 720p stream access: 720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N),When 1080p Lite mode enabled:,1080p lite/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N),Sub-stream: ,2CIF@6fps; CIF/QVGA/QCIF@ 25fps (P)/30fps (N),
Video Bit Rate32 Kbps to 4 Mbps
Dual StreamSupport
Stream TypeVideo, Video & Audio
Audio CompressionG.711u
Audio Bit Rate64 Kbps

Video And Audio
IP Video Input1-ch (up to 5-ch) Up to 960p resolution Support H.264+/H.264 IP cameras
Analog Video Input4ch BNC interface (1.0 Vp-p, 75 ?), supporting coaxitron connection
Turbo HD Input1080p25, 1080p30, 720p25, 720p30
AHD Input1080p25, 1080p30, 720p25, 720p30
HDCVI Input1080p25, 1080p30, 720p25, 720p30
CVBS InputSupport
Audio Input1-ch, RCA (2.0 Vp-p, 1 K?)
Audio Output1-ch, RCA (Linear, 1 K?)
Two-Way AudioReuse the first audio input
Synchronous Playback4ch
VGA/HDMI Output1-ch, 1920 ? 1080/60Hz, 1280 ? 1024/60Hz, 1280 ? 720/60Hz, 1024 ? 768/60Hz

Network
Remote Connections32
Network ProtocolsTCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP?, HTTPS
Network Interface1, RJ45 10M/100M self-adaptive Ethernet interface

Auxiliary Interface
SATA1 SATA interface
CapacityUp to 6 TB capacity for each disk
Alarm In/OutN/A
USB InterfaceRear panel: 2 ? USB 2.0

General
Power Supply12 VDC
Working Temperature-10 ?C to 55 ?C (14 ?F to 131 ?F)
Working Humidity10% to 90%
Weights (Without HDD)? 1 kg (2.2 lb)
Consumption(Without HDD)? 8 W
Dimensions(W ? D ? H)260 ? 222 ? 45 mm (10.2 ? 8.7 ? 1.8 inch)
