Facial Recognition
Face Image Library
Up to 16 face image libraries;
HDD damage will not cause data loss in the face image library, because the library has
been backed up by HDD and flash.
Face Image Comparison 4 chs of face image comparison alarm (HD analog camera)
Motion Detection 2.0
Human / Vehicle Analysis
Deep learning-based motion detection 2.0 is enabled by default for all analog
channels; it can classify human and vehicle, and extremely reduce false alarms caused
by objects like leaves and lights.
Quick search by object or event type is supported.
VCA
Human / Vehicle Analysis Up to 8 chs (advanced model)
Facial Detection
Facial Detection and Capture
Face image detection, face image search
4 chs face picture capture
Video and Audio
IP Video Inputs 8 chs (up to 24-ch), each up to 6 MP
Analog Video Inputs
16 ch
BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
HDMI Output
1 ch, 4K (3840 × 2160) / 30 Hz, 2K (2560 × 1440) / 60 Hz, 1920 × 1080 / 60 Hz,
1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz
CVBS Inputs PAL/NTSC
CVBS Output
1 ch, BNC (1.0 Vp-p, 75 Ω),
Resolution: PAL: 704 × 576, NTSC: 704 × 480
Synchronous Playback 16 chs
HDTVI Inputs
3K (2960 x 1665) @ 25 / 20 fps, 3K (3328x1504) @ 20 fps, 5 MP (2560 × 1944) @ 20 fps,
4 MP (2560 × 1440) @ 25 / 30 fps, 1080p @ 25 / 30 fps, 720p @ 25 / 30 fps
VGA Output 1 ch, 1920 × 1080 / 60 Hz, 1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz
AHD Inputs
5 MP (2560 × 1944) @ 20 fps, 4 MP (2560 × 1440) @ 25 / 30 fps,1080p @ 25 /
30 fps, 720p @ 25 / 30fps
HDCVI Inputs
3K (2880 × 1620) @ 25 / 20 fps, 5 MP (2592 × 1944) @ 20 fps, 4 MP (2560 ×
1440) @ 25 / 30 fps, 1080p @ 25 / 30 fps, 720p @ 25 / 30 fps
Video Output Mode HDMI / VGA simultaneous output
Audio Output 1 ch, RCA (Linear, 1 KΩ)
Audio Inputs 1 ch, RCA (2.0 Vp-p, 1 KΩ)，16 chs via coaxial cable
Two-Way Audio 1 ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input)
Recording
Video Compression H.264 / H.264+ / H.265 / H.265 Pro / H.265 Pro+
Encoding Resolutions
When 1080p Lite mode is not enabled:
3K lite / 5 MP lite / 4 MP lite / 1080p / 720p / VGA / WD1 / 4CIF / CIF
When 1080p Lite mode is enabled:
3K lite / 5 MP lite / 4 MP lite / 1080p lite / 720p lite / VGA / WD1 / 4CIF / CIF
Frame Rates
Main stream:
When 1080p Lite mode not enabled:
 - For 3K stream access: 3K lite @ 12 fps; 4 MP lite @ 15 fps / 1080pLite @ 20 fps;
720p / WD1 / 4CIF / VGA / CIF @ 20 fps
 - For 5 MP stream access: 5 MP lite @ 12 fps; 4 MP lite @ 15 fps / 1080p Lite @ 20
fps; 720p / WD1 / 4CIF / VGA / CIF @ 20 fps
 - For 4 MP stream access: 4 MP lite @ 15 fps / 1080pLite @ 25 fps (P) / 30 fps (N);
720p / WD1 / 4CIF / VGA / CIF @ 25 fps (P) / 30 fps (N)
 - For 1080p stream access: 1080p / 720p @ 15 fps; VGA / WD1 / 4CIF / CIF @ 25
fps (P) / 30 fps (N)
 - For 720p stream access: 720p / VGA / WD1 / 4CIF / CIF @ 25 fps (P) / 30 fps (N)
When 1080p Lite mode enabled:
 - 3K lite / 5 MP lite @ 12 fps; 4 MP lite @ 15 fps; 1080p lite / 720p lite / VGA /
WD1 / 4CIF / CIF @ 25 fps (P) / 30 fps (N)
Sub-stream:
 - WD1 / 4CIF @ 12 fps; CIF @ 25 fps (P) / 30 fps (N)
Video Bitrate 32 Kbps to 6 Mbps
Dual-stream Supports main stream or sub stream
Stream Type Video, Video & Audio
Audio Compression G.711u
Audio Bitrate 64 Kbps
Decoding
Decoding Capability Up to 24 chs 1080p @ 30 fps
Network
Total Bandwidth 256 Mbps
Network Protocol
TCP/IP, PPPoE, DHCP, LTS Connect, DNS, DDNS, NTP, NFS, iSCSI, UPnP™, HTTPS, ONVIF,
ISUP
Remote Connection 128
Network Interface 1 x RJ45 10/100/1000 Mbps self-adaptive Ethernet interface
Auxiliary Interface
SATA 2 x SATA interface, up to 12 TB capacity for each disk
Serial Interface RS-485 (half-duplex)
USB Interface
Front panel: 1 × USB 2.0;
Rear panel: 2 × USB 3.0
Alarm In/Out N/A (optional to support)
General
Power Supply 12 V DC, 3.3 A
Consumption ≤ 40 W
Operating Temperature 14° to 131° F (-10° to 55° C)
Operating Humidity 10% to 90%
Dimensions (W × D × H) 15.1 × 12.5 × 2.0 inch (384 × 317 × 52 mm)
Weight ≤ 4.4 lb (2 kg)
