Intelligent PoE Management. When the power supply exceeds the limit, PoE ports intelligently manage the power supply, which extends the switch lifetime.
Up to 300 m Long Range PoE Transmission. The distance between IPCs and switch can reach maximum 300 meters.
4/8-Core Adaptive Power Supply with Less Power Loss. 8-core power supply reduces the power loss on cables.
6KV Surge Protection to Improve Reliability in Harsh Environment. The built-in surge protection device protects the switch from the sudden lightning surge in harsh environment.
Design for Video Transmission. VIP port ensures important data transmission when network congestion occurs.
Specification
Network Parameters
Ports4 ? 10/100 Mbps PoE ports, and 1 ? 10/100 Mbps RJ45 port
Port TypeRJ45 port, full duplex, MDI/MDI-X adaptive
Working ModeStandard mode (default); Extend mode
StandardIEEE 802.3, IEEE 802.3u, IEEE 802.3x
Forwarding ModeStore-and-forward switching
High Priority PortsPorts 1 to 2
MAC Address Table2 K
Switching Capacity1 Gbps
Packet Forwarding Rate0.744 Mpps
Internal Cache0.768 Mbits
PoE Power Supply
PoE StandardIEEE 802.3af, IEEE 802.3at
PoE Power Pin
End-span: 1/2(-), 3/6(+)
Mid-span: 4/5(+), 7/8(-)
8-pin power: 1/2(-), 3/6(+), 4/5(+), 7/8(-)
PoE PortPorts 1 to 4
Max. Port Power30 W
PoE Power Budget35 W
Dialing Function
Long RangePorts 1 to 4: up to 300 m; and the speed rate of the port is 10 Mbps.
General
Dimensions (W ? H ? D)105 mm ? 27.6 mm ? 83.1 mm (4.1? ? 1.1? ? 3.3?)
ShellMetal material, fan-free design
Gross Weight0.48 kg (1.06 lb)
Net Weight0.20 kg (0.40 lb)
Operating Temperature?10 ?C to 55 ?C (14 ?F to 131 ?F)
Operating Humidity5% to 95% (no condensation)
Storage Temperature?40 ?C to 85 ?C (?40 ?F to 185 ?F)
Storage Humidity5% to 95% (no condensation)
Power Supply48 VDC, 0.8 A
Power Consumption In Idle3 W
Approval
EMCFCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 55024: 2010 +A1: 2015); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016)
SafetyUL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013)
ChemistryCE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
