Data sheet PDF
Product Description
ED8004H5-BN2 || Titanium, DVR, 5MP Lite, 4CH, 1X SATA PORT
? Max Recording Resolution: 5MP Lite
? Channels: 4CH
? LAN Ports: 1
? SATA: 1X SATA PORT
? Video Outputs: HDMI / VGA
? NDAA Compliant: Yes
? Hardware Features: Audio in, Audio out, BNC Video Out
SPECIFICATIONS
ED8004H5-BN2
255? 222? 42( W ? D ? H )
SATA ? 1, up to 10TB
HDMI ? 1 : 1920 ? 1080 / 1280 ? 1024 / 1024 ? 768
VGA ? 1 : 1920 ? 1080 / 1280 ? 1024 / 1024 ? 768
BNC ? 1 : CVBS ( used as the main or spot output )
RS 485 ? 1 (half-duplex)
?5W( without HDD)
Up to 5MP@30fps
DC12V / 1.5A
USB 2.0 ? 2 ( in the rear panel )
TVI/AHD/CVI:5MP/4MP/1080P/720P/WD1
5MP Lite/4MP Lite/1080P/1080P Lite/720P/WD1
Analog Channel: 5MP Lite :10fps; 4MP Lite/1080P : 12fps (PAL)/15fps (NTSC);
1080P Lite/720P/WD1 : 25fps (PAL)/30fps (NTSC)
IP Channel: 25fps (PAL)/30fps (NTSC)
16Mbps(max.36Mbps)
Playback
Network
-10~50?C, 10%~90% (humidity)
RCA ? 1
RCA ? 1 (linear, 600?)
No
No
32Kbps ~ 4Mbps
Manual, timer, motion, smart event
Model
Audio
Working Environment
System
Video
OS
Analog Video Input
IP Video Input
Total Input
Output
Input
Output
Two-way audio
Resolution
Frame Rate
Bit Rate
Mode
Playback
Search
Smart Search
Function
Mode
Input
Output
Interface
Protocol
Incoming Bandwidth
OS
HDD
Local Backup
Network Backup
RS 485
USB
Remote Controller
Power Supply
Consumption
Dimensions(mm)
Embedded Linux
BNC ? 4
2CH (up to 6CH)
4CH
Take up channel one audio input
Time slice / time / event / tag search
Highlight colors to display the camera record in a certain period of time, different colors refer to different record
events
Play, pause, FF, FB, digital zoom, etc.
Manual, motion, exception, smart event
RJ 45 100Mbps ? 1
TCP / IP, IPv4, IPv6, PPPoE, DHCP, DNS, DDNS, UPnP, HTTP, HTTPs, 802.1x, FTP, RTP, RTSP, RTCP, NTP, SMTP, UDP,
Websocket, SNMP, IGMP
iOS, Andriod
U disk, USB mobile HDD
Yes
Optional
Record
Alarm
AI Function
Mobile Device
Storage
Backup
Port
Others
6CH
Compression
Multi-screen Display
Compression
H.264/H.265/H.265+
G.711(U/A)
BNC interface (1.0Vp-p; 75?)
Outgoing Bandwidth
Client Connection
40Mbps
Max. 5 users access
1/4/6/9
Certificate
Environmental Protection
CE, FCC
Comply with Directive EU RoHS, WEEE, REACH
