Data sheet PDF
Product Description
DS-7716NI-Q4/16ports NVR Key Feature ? Up to 16ch IP camera inputs ? H.265+/H.265/H.264+/H.264 video formats ? Up to 1-ch@8 MP or 6-ch@1080p decoding capacity ? Up to 160 Mbps incoming bandwidth ? 4 HDDs for continuous video recording
? Specification Video and Audio IP Video Input 16ch Up to 8 MP resolution Incoming Bandwidth 160 Mbps Outgoing Bandwidth 80 Mbps HDMI Output 1-ch, 4K (4096 x 2160)/30 Hz, 4K (3840 x 2160)/30 Hz, 2K (2560 x 1440)/60 Hz, 1920 x 1080/60 Hz, 1600 x 1200/60 Hz, 1280 x 1024/60 Hz, 1280 x 720/60 Hz VGA Output 1-ch, 1920 ? 1080/60 Hz, 1280 ? 1024/60 Hz, 1280 ? 720/60 Hz Video Output Mode HDMI/VGA simultaneous output Audio Output 1-ch, RCA (Linear, 1 K?) Two-Way Audio 1-ch, RCA (2.0 Vp-p, 1 k ?) Decoding Decoding Format H.265/H.265+/H.264/H.264+ Decoding Capability 1-ch@8 MP (30 fps)/6-ch@1080p (30 fps) *: The length or width of camera resolution (each track) cannot exceed 4096 pixels. Synchronous playback 16ch Recording Resolution 8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF Stream Type Video, Video & Audio Audio Compression G.711ulaw/G.711alaw/G.726 Network Remote Connection 64 Network Protocol TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP?, HTTP, HTTPS Network Interface 1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface PoE Interface 16, RJ-45 10/100 Mbps self-adaptive Ethernet interface Power ? 150 W Supported standard IEEE 802.3 af/at Auxiliary Interface SATA 4, SATA interface Capacity Up to 8 TB capacity for each disk Serial Interface 1 RS-485 (half-duplex), 1 RS-232 USB Interface Front panel: 2 ? USB 2.0; Rear panel: 1 ? USB 2.0 Alarm In/Out 16/4 General Power Supply 100 to 240 VAC, 50 to 60 Hz Consumption ? 15 W (without HDD and PoE off) Working Temperature -10 ?C to 55 ?C (14 ?F to 131 ?F) Working Humidity 10 % to 90 % Dimension (W ? D ? H) 445 ? 400 ? 75 mm (17.5" ? 15.7" ? 3.0") Weight ? 5 kg (without HDD, 11 lb.) Certification FCC Part 15 Subpart B, ANSI C63.4-2014 CE EN 55032: 2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4, EN 55035: 2017
