Product Description

Platinum Professional Level 16 Channel HD-TVI 4.0 DVR

H.265/H.265+ 16CH DVR, 4/1 RCA I/O, 5 in 1, Up to 4K/8MP HD-TVI input, Up to 2-ch 6MP IP cameras input, Support Live View, Storage, Playback up to 16 HD-TVI/Analog Cameras + 2 IP Cameras, Up to 4k HDMI Video Output, CVBS Output, 2 SATA up to 16TB each HDD, 2 USB 2.0

H.265/H.265+ 16 Channel Video Recorder
4/1 RCA I/O
16 channels support HD-TVI / AHD/ ANALOG / CVI / IP input (5 in 1)
16 channels support up to 4K/8MP HD-TVI input
Up to 2-ch 6MP IP cameras input
Support Live View, Storage, Playback up to 16 HD-TVI/Analog Cameras + 2 IP Cameras
Up to 4k HDMI Video Output
CVBS Output
2 SATA up to 16TB HDD
2 USB 2.0

SPECIFICATIONS

Model	LTD8508K-ST	LTD8516K-ST
Recording
Video compression	H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
Encoding resolution	When 8 MP Lite mode is not enabled: 8 MP/5 MP/4 MP/3 MP/1080p/720p/WD1/4CIF/VGA/CIF When 8 MP Lite mode is enabled: 8 MP Lite/5 MP/4 MP/3MP/1080P/720P/WD1/4CIF/VGA/CIF
Frame rate	Main stream: When 8 MP Lite mode is not enabled: 8 MP@8 fps/5MP@12 fps/4 MP@15 fps/3 MP@18 fps 1080p/720p/WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N) When 8 MP Lite mode enabled: 8 MP Lite/5 MP@12 fps/4 MP/3MP/1080P/720P/WD1/4CIF/VGA/CIF@15 fps
Sub-stream: WD1/4CIF/CIF@25fps (P)/30fps (N)
Video bit rate	32 Kbps to 10 Mbps
Dual stream	Support
Stream type	Video, Video & Audio
Audio compression	G.711u
Audio bit rate	64 Kbps
Video and Audio
IP video input	8-ch (up to 16-ch)	16-ch (up to 32-ch)
Up to 8 MP resolution
Support H.265+/H.265/H.264+/H.264 IP cameras
Analog video input	8-ch	16-ch
BNC interface (1.0 Vp-p, 75 ?), supporting coaxitron connection
HDTVI input	8 MP, 5 MP, 4 MP, 3 MP, 1080p30, 1080p25, 720p60, 720p50, 720p30, 720p25
AHD input	5 MP, 4 MP, 1080p25, 1080p30, 720p25, 720p30
HDCVI input	5 MP, 4 MP, 1080p25, 1080p30, 720p25, 720p30
CVBS input	PAL/NTSC
CVBS output	1-ch, BNC (1.0 Vp-p, 75 ?), resolution: PAL: 704 ? 576, NTSC: 704 ? 480
VGA output	1-ch, 1920 ? 1080/60Hz, 1280 ? 1024/60Hz, 1280 ? 720/60Hz, 1024 ? 768/60Hz
HDMI output	1-ch, 4K (3840 ? 2160)/30Hz, 2K (2560 ? 1440)/60Hz, 1920 ? 1080/60Hz, 1280 ? 1024/60Hz, 1280 ? 720/60Hz, 1024 ? 768/60Hz
Audio input	4-ch, RCA (2.0 Vp-p, 1 K?)
Audio output	1-ch, RCA (Linear, 1 K?)
Two-way audio	1-ch, RCA (2.0 Vp-p, 1 K?) (using the first audio input)
Synchronous playback	8-ch	16-ch

Need help?

Our team is here to assist you! If you are unsure what to get, or have any questions about a products, our specialists are here to help.

Call us now

Returns & Delivery

When will my order be delivered?

We ship worldwide. Your order will be packaged really carefully and delivered wherever you want. Delivery takes between 2-4 business days. You will receive an e-mail after ordering with more information about the delivery.

Can I return my product?

Orders can be returned or exchanged within 30 days of receiving the parcel, providing they are in original resalable condition.

What can I do if my item (or part of it) is damaged?

We work hard to deliver your items without damage. Orders can be returned or exchanged within 30 days of receiving the parcel, providing they are in original resalable condition.

LTSLTS LTD8516K-ST 16CH DVR Up to 8MP TVI & AHD Analog CVI 2CH 8MP IP 5in1 4K-UHD

Login

Email*

Password* Toon Hide Forgot your password?

Don't have an account yet?
Create account

Network
Remote connection	64	128
Network protocol	TCP/IP, PPPoE, DHCP, LTS-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP?, HTTPS, ONVIF
Network interface	1, RJ45 10M/100M/1000M self-adaptive Ethernet interface
Auxiliary interface
SATA	2 SATA interfaces
Capacity	Up to 10 TB capacity for each disk
Serial interface	RS-485 (half-duplex)
USB interface	Front panel: 1 ? USB 2.0 Rear panel: 1 ? USB 3.0
Alarm in/out	8/4	16/4
General
Power supply	12 VDC, 3.33 A	12 VDC, 5 A
Consumption (without HDD)	? 20 W	? 25 W
Working temperature	-10 ?C to +55 ?C (+14 ?F to +131 ?F)
Working humidity	10% to 90%
Dimension (W ? D ? H)	380 ? 320 ? 48 mm (15.0 ? 12.6 ? 1.9 inch)
Weight (without HDD)	? 1.78 kg (3.9 lb)	? 2 kg (4.4 lb)
: Normally, only CH1/CH2 support VCA. If "Enhance VCA" mode is on, all channels support VCA, but Max Res only 2MP.*
Network
Remote connection	64	128
Network protocol	TCP/IP, PPPoE, DHCP, LTS-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP?, HTTPS, ONVIF
Network interface	1, RJ45 10M/100M/1000M self-adaptive Ethernet interface
Auxiliary interface
SATA	2 SATA interfaces
Capacity	Up to 10 TB capacity for each disk
Serial interface	RS-485 (half-duplex)
USB interface	Front panel: 1 ? USB 2.0 Rear panel: 1 ? USB 3.0
Alarm in/out	8/4	16/4
General
Power supply	12 VDC, 3.33 A	12 VDC, 5 A
Consumption (without HDD)	? 20 W
