Data sheet PDF

Product Description

ED8016H5-BN2 || Titanium, DVR, 5MP Lite, 16CH, 1X SATA PORT

? Max Recording Resolution: 5MP Lite
? Channels: 16CH
? LAN Ports: 1
? SATA: 1X SATA PORT
? Video Outputs: HDMI / VGA
? NDAA Compliant: Yes
? Hardware Features: Audio in, Audio out, BNC Video Out

16CH 5MP 1SATA Hybrid Titanium DVR ED8016H5-BN2 Features:

• Supports 16 CH TVI / AHD /CVI 5MP / 4MP / 1080P / 720P / WD1 video input
• Supports 8 CH 5MP / 4MP / 3MP / 1080P / 960P / 720P IP video input
• 8CH analog video input can be switched to 8CH IP video input
• Adopt standard H.265 high profile compression format to get high-quality video at a much lower bit rate
• Intuitive and user-friendly Graphics User Interface ( GUI ), window style operation by mouse
• Multi-mode recording: manual / timed / motion / AI recording
• Playback: 16 CH simultaneously playback
• Search: time slice, time, event, tag search
• Express and flexible backup via USB, network, and so on
• Pentaplex: preview, record, playback, backup, and remote access
• DHCP, DDNS, PPPoE network protocol
• Remote control via Web or CMS: preview, playback, backup, PTZ, and configuration
• Dual stream technology for local storage with high definition, remote network transmission, and remote surveillance with a mobile device
• Authorization management, log review, and device status review
• 1080P output, true high-resolution display
• PTZ preset and auto cruise, up to 255 presets and 8 cruises
• Support NAT function and QRCode scanning by mobile phones
• Powerful mobile surveillance by smartphones with iOS and Andriod OS

This 16CH 5MP 1SATA Hybrid Titanium DVR ED8016H5-BN2 is highly recommended to work with:

IP Network Cameras ? TITANIUM IPC

Coaxial Cameras ? Titanium HD Cameras
